Coreless pe coated food paper rewinder

2 shaft bubble wrap film slitter rewinder is a downstream processing unit for bubble wrap film production lines. It is primarily used for slitting and rewinding various materials, including bubble wrap film, plastic films (PE, PVC, PET, BOPP, etc.), paper, and composite films used in flexible packaging.

Features:
1. Two-shaft design allowing both rewinding shafts to operate simultaneously, significantly boosting production efficiency.
2. Typically utilizes air-expanding shafts of rewinding shaft for convenient loading and unloading of rolls.
3. Usually employs straight-blade slitting, ensuring smooth cutting edges and neat, uniform slit faces.
4.It is centrally controlled by a PLC and operated via a touchscreen HMI; parameters such as slitting width, length, and speed can be preset.

Main Data:

Name: 2 Shaft Bubble Wrap Film Slitter Rewinder

Model: PPD-BFSR1600

Effective Slitting Width: 100–1500 mm

Slitting Thickness: 0.5–5 mm

Speed: 80–100 m/min

Unwinding Diameter: Max. 1200 mm

Unwinding Magnetic Powder Brake: 5 kg brake

Rewinding Magnetic Powder Brake: 50 NM

Rewinding Diameter: Max. 600 mm

Power: 4 kw

Voltage: 380/415V, 50Hz
