Coreless stretch film rewinder

PPD-LFSR1800

Laser Film Slitter Rewinder

Laser film slitter rewinder is suitable for slitting and rewinding of various roll materials such as plastic film, polyester film, laser film, OPPP film, BOPP film, PET film, non-woven fabric, etc. According to different needs in the production process Trimming, slitting, etc.

Features
1. Machine adopts the method of center coiling and surface contact and coiling
2. Automatic meter counting, alarm and other functions;
3. The rewinding adopts the structure of A and B inflatable shafts, which is convenient for loading and unloading;
4. The unwinding adopts photoelectric automatic correction system, so that irregular materials can be cut normally
5. Flat knife slitting waste edge automatic discharge device
6. Manual feeding, with air tent shaft (3 inches).

Technical Data:

Name: Laser Film Slitter Rewinder

Model: PPD-LFSR1800

Unwinding width: max1800mm

Unwinding diameter: up to 600mm

Inner diameter of unwinding paper core: 76 MM

Rewinding diameter: maximum 400MM

Inner diameter of winding paper core: 76 MM

Slitting and rewinding width: 100mm--1800mm

Speed: 10-200m/min

Main motor 5.5KW

Voltage: 380V, 50hz
