Automatic pre stretch film rewinder

Fully automatic pre stretch film rewinding machine is designed for the rapid rewind stretch film from jumbo roll into small rolls by pre stretch. By pre-stretch,the stretch film can rewind different length from 100-300% due to different ratio setting.
The machine is user friendly,high speed.A non skilled operator can run the machine,maximum can operate 3 units of machines,by special designed automatic convery belt system to join the several machines products into one packaging area


Features:
1.Automatic control for speed adjustment
2.Automatic paper core change program, make increase the efficiency.
3.User friendly by PLC program and touch screen
4.Pre-stretch ratio to be adjustment according to buyer request.
5.Safety Guarding and controls C E certified

Technical Data:

Name:Fully Automatic Pre Stretch Film Rewinding Machine

Model:PPD-APR600

Film width:Max600mm

Rewinding width:Max600mm

Max.diameter of Jumbo roll:500mm

Jumbo roll paper core diameter:76mm

Diameter of rewind roll:Max160mm

Pre stretch rewind speed:650m/min

Standard stretch rewinder speed:900m/min

Paper core changing:Automatic

Main power:4.5kw

Core size of rewinder:1.5/2/3inch

Voltage:220/380/415V option
