PPD-PPSR450
-
Automatic parchment paper slitter rewinder is our customized model to rewind the jumbo roll parchment paper to produce small product rolls.
As a multi-function slitter rewinder machine,our this model can rewind the baking paper,silicon paper and aluminium foil,kitchen foil,wax paper etc..
Machine is easy to use and high production speed,with 4 shafts rewinding,our machine can rewind 5 meters product rolls 10 rolls per minute.Features:
1: The product is rewinded at 4 shafts,the paper core will be replaced automatically when the setted product meter is reached. The machine has a fast production speed and is an ideal model for short meters products,such as 5 meters,10 meters,20 meters etc..The maximum rewinding length of the machine is at 150 meters (depending on the inner diameter and size of the paper tube).
2: Machine is easy to operate and easy to maintain. Machine is equipped with an automatic tension system and an automatic meter counting system.
3: PLC touch screen, ABB inverter,china top brand machine parts makes our machine high quality and long time working.Our machine can hold heavy duty production for 24/7 operation.
Machine data:
Machine name:Automatic parchment paper slitter rewinder
Machine model:PPD-PPSR450
Parent roll width:max 450mm(adjustable)
Parent roll outer diameter:max 800mm
Parent roll inner diameter:3/6 inch
Parent roll loading method:Air shaft
Baby roll inner diameter:25/30/38m
Baby roll length:maxim 150meters
Speed: max 150m/min
Machine voltage:220/380/415/450v,3ph
Machine power:4 kw
Machine net weight:1700kg
