PPD-ASR500
-
Air shaft model stretch film slitting rewinding machine is our new stretch film slitting rewinding model.
We use the air shaft slitting rewinding insteand of mandrel slitting rewinding,it is more easy and high production output.Compared with the standard stretch film slitting rewinding model,the efficiency is improved by at least 30%.
Machine can also do the standard stretch film rewinding as buyer requirement.Features:
1:Air shaft slitting rewinding model,compared with the standard stretch film slitting rewinding model,the efficiency is improved by at least 30%.
2:With adjust the slitting knife width,can get different width of product rolls.
3:As a multi-function model,machine can also do the standard stretch film rewinding as buyer requirement.
4:Automatic meter counting,machine will stop once reach the setting length.
Machine data:
Machine name:Air shaft model stretch film slitting rewinding machine
Machine model:PPD-ASR500
Jumbo roll width:500mm
Jumbo roll outer diameter:400mm
Jumbo roll inner diameter:76mm(3inch)
Jumbo roll loading method:Pneumatic cylinder
Small roll inner diameter:38,50,76mm(option)
Small roll width:50mm to max jumbo roll width
Small roll loading method:Air shaft
Speed:max 600rpm/min
Voltage:220/380/415/450v,3ph(option)
Power:2.37kw
