Stretch film rewinding machine

Automatic stretch film 16kg roll rewinding machine is designed for some market demands for 15kg,16kg roll rewinding.it is suited for both machine roll and hand roll rewinding for pallet stretch wrap,hand stretch wrap.food stretch wrap etc.

Machine built by PLC programmer device+LCD touch screen for user firendly.Speed is flexible controlld by inverter.With pneumatic cylinder controlled receiving plate,it will automatic bring down of the ready roll to deliver to convery system to avoid the damage the roll when of dropping.

Main data:

Name:Automatic Stretch Film 16KG Roll Rewinding Machine

Model:PPD-ARW550-16KG

Material:Stretch film

Max width jumbo roll:550mm

Max OD of jumbo roll:500mm

Jumbo roll ID:3inch

Rewind roll width:300-550mm

Rewind roll ID:38/50/76mm

Rewind roll weight:1-16kg

Speed:max1200m/min

Power:4kw

Volt:220/380/415/450v,3ph

Individual requirement is acceptable.
