Semi automatic cling film rewinder

PPD-SACFR300

Semi Automatic Cling Film Rewinder

Semi automatic cling film rewinder is used for rewinding of PVC cling film,PE cling film,PE stretch film etc from jumbo roll to small diameter hand roll.
Machine works with PLC programm,human machine interface setting and inverter control system, easy to operate.
Automatic counting,once machine reach the setting length,machine will automatic stop.

Main Data:

Name:Semi Automatic Cling Film Rewinder

Model:PPD-SACFR300

Width of jumbo roll:300mm

ID of jumbo roll:76mm

OD of jumbo roll:max400mm

Width of rewind roll:300mm

OD of rewind roll:max100mm

ID of rewind roll:30/35/38mm or as customized

Machine production speed:max500m/min

Voltage:220/380/415V ,3ph,50hz

NOTE:Different sizes can be customized.
