Coreless pe coated food paper rewinder

PVC wallpaper rewinding machine is suitable for rewinding various materials such as PVC wallpaper,gift paper, book cover,window film,craft papera,water prooff material and other decorative materials etc.

Features:
1.The whole machine adopts servo motor to control the feeding,PLC touch screen automatically counts the number of meters, automatically cuts off, and the parking time is freely set.
2. Automatic discharge device for longitudinal cutting at the end.
3. Pneumatic automatic feeding, rewinding and releasing air shaft.
4.Every time, would running a certain length for prewinding on air shaft

Technical Data:

Name:PVC Wallpaper Rewinding Machine

Model:PPD-WPP1000

Web roll width:1020mm

Web roll diameter:max800mm

Paper core diameter:38.5mm(1.5inch)

Rewinding speed:10-180m/min

Finished product width:max1020mm

Finished product diameter:max200mm

Total power:3kw

Voltage:380V,50Hz
