Aluminium foil food paper rewinder

Coreless silicon paper rewinder with auto label sticker is the perfect solution for rewinding process. Machine is designed with a six-axis rewinding capability that enables it to handle large volumes of rolls quickly and effortlessly. Its automatic labeling feature ensures that the silicon paper remains intact and prevents it from scattering or becoming damaged.

Additionally, the mechanical arm is a significant advantage of this machine, as it automatically pushes the rewound rolls out of the machine, reducing the need for manual labor, hence improving the safety of the operator.



Features:
1.Machine adopst PLC and touch screen for simple operation.
2.The air shaft loading of unwinding, make the loading more convenient and operation more safer.
3.Suitable rewind mateirals:silicon paper,baking paper,parchment paper,wax paper,PE coated paper,bakery paper,food craft paper etc.

Main Data:

Name:Coreless Silicon Paper Rewinder With Auto Label Sticker

Model:PPD-CSPRL450

Width of unwinding roll :maximum450mm

Outer diameter of unwinding roll:max600mm

Inner diameter of unwinding roll:76mm(3inch)

Loading method of unwinding roll:Pneumatic cylinder

Inner diameter of rewind roll: 25mm

Length of rewind roll:max60m

Working speed:max 600rpm/min

Voltage:220/380/415/450V,50Hz

Power:2.5 kw
