Kitchen foil roll rewinder

Automatic 6 shaft aluminum foil rewinder is latest model for fully auto production machine for rewinding of aluminium foil kitchen roll,catering roll etc.
Machine is with 6 shaft automatic changing by non stop production,it increases the production rate at 30-50% than the conventional model.
This model is installing the special made automatic labelling unit for fully auto labelling after the rewinding.By PLC man-machine interface talk device,LCD touch screen,the operation is at simple way,non-skilled work can operate the machine.
Machine is with automatic laoding paper core,on the rewinding clamp,automatic starting,auto rewinding,auto stop when reaching the length setting,auto cut off the finished roll,auto unloading the finished roll,auto changing the paper core,automatic labeling.




Machine Data:

Material:kitchen foil,house foil

Unwind roll width:max 450mm

Unwind roll inner diameter:3/6inch

Unwind roll outer diameter:600mm

Rewinding roll width:max 450mm

Rewinding inner dia:25/35/38/40mm

Rewinding roll length:2-150mtrs

Speed:150m/min

Power:4kw

Volt:220/380/415/450v

Air consumption:0.3Mpa
