Auto stretch film rewinding machine

PPD-3SH500

High Speed Automatic 3 Shaft Stretch Film Rewinder

High spedd automatic 3 shaft stretch film rewinder is design for high speed production for converting the jumbo roll of stretch film into small machine roll,hand roll etc.
It is 3 turret for rapidly changing of the paper core from the ready roll into next one.
The production speed is at about 30-50% higher than the conventional model.

Features:
1. PLC program+ human-machine interface + inverter control system, high degree of automation;
2. Man-machine interface manual and input interface display, easy to operate, convenient for fault checking;
3. Automatically lowering the paper core, replacing the paper core, automatic heat cutting.
4.Machine works with conveyor belt and receiving table,it can complete the operation of the machine and the packing of the finished product more efficient.

Main parameters:

Name:High Speed Automatic 3 Shaft Stretch Film Rewinder

Model:PPD-3SH500

Material: LDPE stretch film,PE food stretch wrap,PVC food cling film etc

Mother roll width : 500mm

Mother roll outer diameter: max 500mm

Mother roll inner diameter: 3inch

Rewinding roll width: 500mm

Rewinding roll inner diameter: 1.5/2/3inch

Rewinding roll outer diameter:max160mm

Machine design speed:1500m/min

Total power: 4.0kw
