Pre stretch film rewinder

PPD-DL450

Dotted Line Type High Speed Cling Wrap Rewinder

Dotted line type high speed cling wrap rewinder is ideal for PE PVC cling wrap film rewinder,it is with dotting line rewinding by 300x300mm,or any other size by pre set.
It is easy for tear away when wrap the food or others.
5 shaft exchange rewinding to reduce the time ofchanging the paper core to increase the produciton speed.
Build with PLC program,touch screen for user friendly.
Adjustable tension control,self-diagnosis when appear error on the screen.

Technical Specs:

Name:Dotted Line Type High Speed Cling Wrap Rewinder

Model:PPD-DL450

Type:Dot line or standard

Material:PE PVC cling wrap

Max width of mother roll:300mm

Paper core dameter of mother roll 76mm

Rewind roll with dot line 300x300mm

Speed:max650m/min

Rewind roll paper core diameter:25/32/38mm

Power:5.5kw

Voltage:220/380/415V,50hz
