Auto cling film rewinding machine

Automatic single shaft aluminium foil rewinder is design for rewinding above 150meter roll.
Machine works with one shaft rewinidng,touch screen,PLC and inverter control,automatic glue spraying,automatic rewinding and automatic change to next roll and automatic put the finished roll to conveyor system.

Features:
1.Automatic conveyor roller system to receiving of finished roll.
2.Rewind length can be set,like 5m,10m,50m,100m,200m,300mm,max to 530m.
3.Machine speed 0-100m/min adjustable.

Main Data：

Name:Automatic Single Shaft Aluminium Foil Rewinder

Model:PPD-ASAFR450

Foil thickness:10-20micron

Jumbo roll width:450mm

Jumbo roll ID:76/152mm

Jumbo roll weight:max500kgs

Rewind roll width:max450mm

Rewind roll ID:30/35/38/40mm option

Rewind roll OD:max103mm

Rewind roll length:max530m

Speed:0-100m/min

Voltage:220/380/415V,50Hz
